주요 사항

  • 10 MHz까지 주파수 범위 업그레이드 가능
  • 임피던스 측정 시 ±0.05 % 기본 정확도
  • 위상 측정 시 ±0.03° 기본 정확도
  • 최대 40 V의 DC 바이어스
  • 데이터 로깅 기능

전문가를 위한 최고의 구성요소 테스트 기기

R&S®LCX LCR Meter는 다양한 작업을 지원하며 매우 정확하고 빠른 측정 성능을 제공합니다. 이 기기는 연구개발 및 생산 부문의 까다로운 작업에 최적입니다. 두 가지 기기 모델과 다양한 옵션이 지원되므로 테스트 신호 주파수가 최대 10 MHz인 작업에서 활용할 수 있습니다. 내부 및 외부 바이어스 기능과 광범위한 분석 옵션, 다양한 목적에 적합한 테스트 장치를 활용해 가능한 운용 범위를 크게 확장할 수 있습니다.

기능 및 장점

빠르고 정확한 성능, 다양한 활용성

두 가지 R&S®LCX 모델 모두 빠른 측정 속도와 높은 정확도, 다양한 목적에 적합한 측정 성능을 제공합니다. 따라서 개발 부문의 일반 측정, 연구 부문의 소재 분석뿐만 아니라 빠른 생산 테스트에서도 적합합니다. 측정 범위가 광범위하므로 극히 낮거나 높은 임피던스의 운용 목적에도 활용 가능합니다. 세 가지 측정 시간이 지원됩니다.

  • 빠름: ≤ 15 ms
  • 보통: ≤ 100 ms
  • 느림: ≤ 500 ms
임피던스 측정의 기본 정확도는 ±0.05 %이며 위상 측정의 경우 ±0.03°입니다.

주파수 범위 선택 가능

모든 R&S®LCX 모델은 DC 조건에서 측정합니다. AC 범위는 무려 4 Hz부터입니다. R&S®LCX100의 주파수 상한은 300 kHz입니다. R&S®LCX200의 기본 구성은 최대 주파수인 500 kHz에 맞게 설계되었습니다. 이 주파수 상한은 1 MHz 또는 10 MHz까지 확장 가능합니다. 따라서 운용 목적과 예산에 따라 최적의 기기를 구성할 수 있습니다.

모든 요구사항에 적합한 테스트 신호

100 mV ~ 10 V 범위에서 테스트 신호를 발생할 수 있으며, 최대 200 mA까지 전류를 제공합니다. 출력 임피던스는 100 Ω 또는 10 Ω 중에서 선택할 수 있습니다. 적용된 실제 전류 흐름과 전압은 모니터 기능을 사용해 측정합니다.

DC 바이어스

대부분의 운용 환경에서는 서로 다른 작동점에서 C 및 L 성분을 측정하기 위해 DC 바이어스를 조절할 수 있어야 합니다. R&S®LCX100 및 R&S®LCX200은 최대 10 V의 DC 바이어스 전압을 발생합니다. 또는 DC 바이어스 전류(최대 200 mA)를 설정할 수 있습니다. 예를 들어 R&S®NGA의 경우 일반 DC 전원공급장치를 사용하여 후면 패널(R&S®LCX-K108 옵션)의 외부 접속부에 최대 40 V의 DC 바이어스 전압을 적용할 수 있습니다.

데이터 로깅 기능

R&S®LCX LCR Meter는 모든 측정값에 대해 빠른 로깅 기능을 제공합니다. 데이터를 외부 USB 플래시 드라이브에 저장하거나 USB 또는 LAN을 통해 외부 PC로 전송할 수 있습니다. 최대 10 sample/s의 데이터 속도로 매 100 ms초마다 측정값을 확인할 수 있습니다.

사용 가능한 옵션

하드웨어 옵션
산물
설명
R&S®NG-B105

주문 번호 5601.6000.02

설명

IEEE-488 (GPIB) 인터페이스

소프트웨어 옵션
산물
설명
R&S®LCX-K106

주문 번호 3630.1922.03

설명

고급 분석 기능

R&S®LCX-K107

주문 번호 3660.7741.03

설명

디지털 I/O 포트 및 구간화(Binning) 기능

R&S®LCX-K108

주문 번호 3692.9791.03

설명

확장 바이어스 기능

R&S®LCX-K201

주문 번호 3630.1880.03

설명

주파수 1 MHz로 업그레이드, R&S®LCX200용

R&S®LCX-K210

주문 번호 3630.1900.03

설명

주파수 10 MHz까지 업그레이드, R&S®LCX200용

액세서리
산물
설명
R&S®LCX-Z1

주문 번호 3639.2296.02

설명

축방향/방사형 리드 유형 장치용 테스트 픽스처

R&S®LCX-Z2

주문 번호 3638.6446.02

설명

켈빈 클립 리드

R&S®LCX-Z3

주문 번호 3639.2509.02

설명

SMD 구성품용 테스트 픽스처

R&S®LCX-Z4

주문 번호 3639.2515.02

설명

SMD 구성품용 테스트 핀셋

R&S®LCX-Z5

주문 번호 3639.2521.02

설명

변압기 테스트 케이블

R&S®LCX-Z11

주문 번호 3639.2538.02

설명

BNC 확장 케이블, 길이: 1 m

R&S®ZZA-GE23

주문 번호 5601.4059.02

설명

19" 랙 어댑터, 2 HU

Educational note: Understanding transformer testing

Educational note: Understanding transformer testing

Transformers are passive devices that are primarily used to convert or "transform" alternating current (AC) from one voltage level to another. One very common application of transformers is in AC to DC power supplies, in which mains voltage is stepped down before being rectified and filtered to produce DC. There are numerous other applications for transformers, such as providing electrical isolation or for impedance matching.

Read this educational note and dive into the discussion about the six most important transformer measurements: turns ratio, mutual inductance, phase angle, primary and secondary inductance, leakage inductance, and interwinding capacitance.

Related videos

Webpage, VNC & FTP on R&S®DC Power Supplies

Learn how easy it is to control and operate our instrument from any location via ethernet-based remote services

Impedance Measurements using R&S®LCX200 & MFIA

The LCR Meters and Impedance Analyzers from Rohde & Schwarz are ideal for measuring impedance at a fixed frequency as well as for determining the best operating point for the component under test

R&S®LCX Test Fixtures

The R&S®LCX Z1/Z2/Z3/Z4/Z5 test fixtures from Rohde & Schwarz can perform measurements on a wide range of components.

Transformer Testing With R&S®LCX200 and R&S®LCX-Z5

The R&S®LCX-Z5 test fixture is designed for measuring transformers in combination with the measurement functions of the R&S®LCX LCR meters.

R&S®LCX-K106 Advanced Analysis Function Sweep Tool

R&S®LCX LCR 미터의 스윕 툴은 테스트 신호 주파수, 레벨, DC 바이어스를 스윕하여 동적 임피던스 측정을 지원합니다.

R&S®LCX100 및 R&S®LCX200의 핵심 기능

R&S®LCX LCR Meter에는 고분해능 터치스크린, 최대 10 MHz의 주파수 지원, 다양한 측정 기능과 로깅 기능이 탑재되어 있습니다.

R&S®LCX-K108 Extended Bias 기능

R&S®LCX-K108 옵션을 사용하면 최대 10V의 외부 DC 전압 바이어스와 최대 200mA의 내부 DC 전류 바이어스를 DUT에 적용할 수 있습니다.
