R&S®RTO6 oscilloscope

Instant insight meets in-depth information

R&S®RTO6 oscilloscope
Open Lightbox
R&S®RTO6 oscilloscope
Open Lightbox
R&S®RTO6 oscilloscope
Open Lightbox
R&S®RTO6 oscilloscope
Open Lightbox
R&S®RTO6 oscilloscope
Open Lightbox
R&S®RTO6 oscilloscope
Open Lightbox
R&S®RTO6 oscilloscope, Front view R&S®RTO6 oscilloscope R&S®RTO6 oscilloscope R&S®RTO6 oscilloscope, Front High R&S®RTO6 oscilloscope, Front High R&S®RTO6 oscilloscope

Key facts

  • 6 GHz maximum bandwidth
  • 1 million waveforms per second
  • 9.4 ENOB for ultimate signal integrity
  • 2 Gpoints maximum memory
  • Exclusive frequency zone trigger

Starting at 27 600 €

The oscilloscope you can trust

The R&S®RTO6 is the oscilloscope you can trust. Engineered to deliver reliable results, it acts as a sophisticated laboratory companion to solve measurement problems fast and keep you on schedule. The R&S®RTO6 oscilloscope series leverages the engineer’s expertise and builds your measurement confidence by achieving deep insights, whenever needed.

The R&S®RTO6 oscilloscope series provides superior signals to insight for your applications. The large 15.6" touchscreen and a new GUI, combined with high waveform update rate, excellent signal fidelity, digital trigger and deep responsive memory serve as a fully integrated test solution for frequency, protocol and logic analysis. The R&S®RTO6 oscilloscope series’ rich measurement toolset combined with a streamlined user interface helps you quickly solve circuit issues from simple to complex.

Features & benefits

Finding signal anomalies quickly

... with an unparalleled update rate

  • 1 000 000 waveforms/s
  • Available with active histograms, masks or cursor measurements
  • Quickly and reliably detect sporadic signal faults
  • Mask testing: Quick configuration and fast results

Typical update rate (left) vs. 1 million waveforms/s (right)
Open Lightbox

Typical update rate (left) vs. 1 million waveforms/s (right)

Capturing all signal details

... with excellent signal integrity

  • Low-noise frontends and minimized crosstalk
  • Flat frequency response
  • Excellent longterm stability
  • Outstanding A/D converter with ultra-wide SFDR

Measured frequency response of the R&S®RTO6
Open Lightbox

Measured frequency response of the R&S®RTO6

Seeing more

... with up to 16 bit resolution

  • 16 bit resolution for measuring small signal amplitudes
  • High acquisition rate and full functionality
  • Full sample rate – No aliasing
  • User-selectable filtering: Reduced noise, increased ENOB

Typical vertical resolution (left) vs. 16 bit resolution HD Mode (right)
Open Lightbox

Typical vertical resolution (left) vs. 16 bit resolution HD Mode (right)

Finding complex signal details

... with advanced trigger capabilities

  • Patented digital trigger system
  • High trigger sensitivity at full bandwidth
  • Isolate smallest signal details
  • Zone trigger in time and frequency domain

Trigger not possible (left) vs. straightforward triggering with digital trigger and HD Mode (right)
Open Lightbox

Trigger not possible (left) vs. straightforward triggering with digital trigger and HD Mode (right)

Measuring more

... with deep and responsive memory

  • Maximized memory: 200 Mpoints standard
  • 2 Gpoints optional
  • Segmented memory to capture distant trigger events
  • History mode to analyze previous trigger events
  • Search and navigation: find faults fast

Single-shot versus segmented acquisition
Open Lightbox

Single-shot versus segmented acquisition

Available models

Available models
Models
Bandwidth
Channels
Sample rate
Max. memory depth
Optional MSO

R&S®RTO64

Order number 1802.0001.04

Bandwidth
600 MHz - 6 GHz
Channels
4
Sample rate
up to 20 Gsample/s
Max. memory depth
2 Gpts
Optional MSO
16 digital channels
Specifications
Vertical system
Analog channels 4
Bandwidth (-3 dB) R&S®RTO64 with R&S®RTO6-B90 option 600 MHz
(one bandwidth option mandatory) R&S®RTO64 with R&S®RTO6-B91 option 1 GHz
R&S®RTO64 with R&S®RTO6-B92 option 2 GHz
R&S®RTO64 with R&S®RTO6-B93 option 3 GHz
R&S®RTO64 with R&S®RTO6-B94 option 4 GHz
R&S®RTO64 with R&S®RTO6-B96 option on 2 channels: 6 GHz
on 4 channels: 4 GHz
Rise time R&S®RTO64 with R&S®RTO6-B90 option 635 ps
R&S®RTO64 with R&S®RTO6-B91 option 375 ps
R&S®RTO64 with R&S®RTO6-B92 option 210 ps
R&S®RTO64 with R&S®RTO6-B93 option 145 ps
R&S®RTO64 with R&S®RTO6-B94 option 110 ps
R&S®RTO64 with R&S®RTO6-B96 option 77 ps
Vertical resolution 16-bit system architecture
Effective number of bits / ENOB (meas.) at 50 Ω, 50 mV/div, 10 MHz input signal with 90 % full-scale
50 MHz
100 MHz
200 MHz
300 MHz
500 MHz
1 GHz
2 GHz
4 GHz
6 GHz

9.4
9.0
8.6
8.2
8.1
7.7
7.1
6
6
RMS noise floor at 50 Ω, 1 mV/div, 10 MHz bandwidth filter 10 µV (meas.)
Input impedance 50 Ω ±1.5 %
1 MΩ ±1 % at 15 pF (meas.)
Input sensitivity max. bandwidth in all ranges 50 Ω: 1 mV/div to 1 V/div
1 MΩ: 1 mV/div to 10 V/div
Acquisition system
Realtime sampling rate R&S®RTO6-B90, R&S®RTO6-B91, R&S®RTO6-B92, R&S®RTO6-B93 options max 10 Gsample/s on each channel
R&S®RTO6-B94, R&S®RTO6-B96 options max. 10 Gsample/s on 4 channels
max. 20 Gsample/s on 2 channels
Acquisition memory standard  200 Mpoints on 4 channels
400 Mpoints on 2 channels
800 Mpoints on 1 channel
R&S®RTO6-B104 option  400 Mpoints on 4 channels
800 Mpoints on 2 channels
800 Mpoints on 1 channel
R&S®RTO6-B110 option  1 Gpoint on 4 channels
2 Gpoints on 2 channels (restriction: 1 Gpoint on 2 channels when channel 1 and channel 2 or channel 3 and channel 4 are turned on)
2 Gpoints on 1 channel
Max. acquisition rate 1 000 000 waveforms/s
Decimation modes any combination of decimation mode and waveform arithmetics on up to 3 waveforms per channel sample, peak detect, high resolution, root mean square
Waveform arithmetics off, envelope, average
Interpolation modes linear, sin(x)/x, sample&hold
Deembedding (optional) yes
Horizontal system
Timebase range 25 ps/div to 10,000 s/div
Timebase Accuracy after delivery/calibration ±10 ppb
Trigger system
Standard Trigger types edge, glitch, width, runt, window, timeout, interval, slew rate, data2clock, pattern, state, serial pattern, TV/video, zone trigger
Optional Trigger types serial bus trigger
Trigger sensitivity definition of trigger hysteresis automatic or manually adjustable
from 0 div to 5 div
Analysis and measurement
Automatic measurements 47
Cursor measurements 4
Waveform mathematics advanced (formula editor)
Mask testing
Mask definition advanced (user-configurable, hardware based)
Logic analyzer (MSO) functionality
Digital input channels 16
MSO Memory depth 200 Mpts per channel
MSO Bandwidth 400 MHz
MSO sampling rate 5 Gsample/s per channel
General data
Dimensions W x H x D 450 mm × 315 mm × 204 mm
(17.72 in × 12.40 in × 8.03 in)
Weight 10.7 kg (23.59 lb)
Interfaces 1 Gbps LAN, type A: 2 x USB 3.1, 2 x USB 2.0, type B: 1 x USB 3.1, GPIB (optional), HDMI and DisplayPort for external monitor, external trigger, trigger output
Display 15.6" capacitive touchscreen, resolution: 1920 x 1080 pixel (Full HD)
Operating system Windows

Available options

Hardware options
Product
Description

Order number 1801.6741.02

Description

Mixed signal option: 16 digital channels, 5 GSa/s, 400 MHz bandwidth

Order number 1801.6735.02

Description

Digital Extension Port for R&S®RTO6. Required for R&S®RT-ZVC02 and R&S®RT-ZVC04 Hardware. Included in R&S®RTO-B1.

Order number 1801.6758.02

Description

Arbitrary waveform generator: 2-channel 500 MSample/s waveform generator and 8-channel pattern generator

R&S®RTO6-B7

Order number 1801.6764.02

Description

Differential 16 GHz pulse source for R&S®RTO6 Oscilloscope

Contains an accessory bag with 2 SMA cables, 4 SMA terminations, 2 SMA(f) to SMA(f) adapters, 2 SMA shorts and 1 ESD wrist strap with grounding cord.

R&S®RTO6-B10

Order number 1801.6770.02

Description

GPIB Interface

R&S®RTO6-B19

Order number 1801.6787.02

Description

Replacement SSD, pre-installed with OS and oscilloscope firmware

Memory upgrade
Product
Description
R&S®RTO6-B104

Order number 1801.6793.02

Description

Memory upgrade to 400 Mpoints on 4 channels, 800 Mpoints on 2 channels

R&S®RTO6-B110

Order number 1801.6806.04

Description

Memory upgrade to 1 Gpoints on 4 channels, 2 Gpoints on 2 channels

Bandwidth upgrade
Product
Description
R&S®RTO6-B201

Order number 1801.7277.02

Description

Upgrade of the R&S®RTO6-B90 option to 1 GHz bandwidth

R&S®RTO6-B202

Order number 1801.7283.02

Description

Upgrade of the R&S®RTO6-B90 option to 2 GHz bandwidth

R&S®RTO6-B203

Order number 1801.7290.02

Description

Upgrade of the R&S®RTO6-B90 option to 3 GHz bandwidth

R&S®RTO6-B204

Order number 1801.7302.02

Description

Upgrade of the R&S®RTO6-B90 option to 4 GHz bandwidth

R&S®RTO6-B206

Order number 1801.7319.02

Description

Upgrade of the R&S®RTO6-B90 option to 6 GHz bandwidth

R&S®RTO6-B212

Order number 1801.7325.02

Description

Upgrade of the R&S®RTO6-B91 option to 2 GHz bandwidth

R&S®RTO6-B213

Order number 1801.7331.02

Description

Upgrade of the R&S®RTO6-B91 option to 3 GHz bandwidth

R&S®RTO6-B214

Order number 1801.7348.02

Description

Upgrade of the R&S®RTO6-B91 option to 4 GHz bandwidth

R&S®RTO6-B216

Order number 1801.7354.02

Description

Upgrade of the R&S®RTO6-B91 option to 6 GHz bandwidth

R&S®RTO6-B223

Order number 1801.7360.02

Description

Upgrade of the R&S®RTO6-B92 option to 3 GHz bandwidth

R&S®RTO6-B224

Order number 1801.7377.02

Description

Upgrade of the R&S®RTO6-B92 option to 4 GHz bandwidth

R&S®RTO6-B226

Order number 1801.7383.02

Description

Upgrade of the R&S®RTO6-B92 option to 6 GHz bandwidth

R&S®RTO6-B234

Order number 1801.7390.02

Description

Upgrade of the R&S®RTO6-B93 option to 4 GHz bandwidth

R&S®RTO6-B236

Order number 1801.7402.02

Description

Upgrade of the R&S®RTO6-B93 option to 6 GHz bandwidth

R&S®RTO6-B246

Order number 1801.7419.02

Description

Upgrade of the R&S®RTO6-B94 option to 6 GHz bandwidth

General analysis
Product
Description

Order number 1801.6829.02

Description

Jitter analysis

Order number 1801.6835.02

Description

Clock data recovery

Order number 1801.6858.02

Description

Power analysis

Order number 1801.6870.02

Description

Spectrum analysis

R&S®RTO6-K39

Order number 1803.6778.02

Description

Python interface for user defined math

Order number 1801.6887.02

Description

Deembedding for compensation of channel effects

Order number 1801.8109.02

Description

Embedding & Equalization

Embedding user-configurable components, predistortion at TX  and equalization at RX via CTLE, FFE or DFE

Order number 1801.6893.02

Description

TDR/TDT analysis

Order number 1801.6906.02

Description

Jitter decomposition: Decomposition of jitter components, display of step response, histograms, synthetic eye diagrams, spectrum and BER-bathtub curve

Order number 1801.7677.02

Description

Jitter and noise decomposition

Order number 1801.8050.02

Description

PAM-N Analysis

Enabled for advanced jitter & noise, advanced eye and selected automated time/amplitude and eye measurements.

Order number 1801.8080.02

Description

Advanced Eye Analysis

Including SW-CDR and comprehensive Mask test library.

Serial triggering and decoding
Product
Description

Order number 1801.6864.02

Description

Bus analysis: Bus measurements and analysis functions

Order number 1801.7019.02

Description

Trigger & decode package "Low speed serial buses": I2C, SPI, RS-232, UART, I2S, LJ, RJ, TDM, Manchester, NRZ

Order number 1801.7025.02

Description

Trigger & decode package "Automotive protocols": CAN incl. CAN-dbc file import, CAN-FD, LIN, FlexRay™ incl.
Fibex file import, SENT, CXPI

Order number 1801.7031.02

Description

Trigger & decode package "Aerospace protocols": MIL-STD-1553, ARINC 429, SpaceWire

Order number 1801.7048.02

Description

Ethernet protocols trigger and decode package: 10BASE-T, 100BASE-TX, MDIO

Order number 1801.7054.02

Description

Trigger & decode MIPI RFFE

Order number 1801.7060.02

Description

Trigger & decode package "Automotive Ethernet": IEEE 100BASE-T1, IEEE 1000BASE-T1

Order number 1801.7077.02

Description

Trigger & decode package "USB protocols": USB 1.0/1.1, USB 2.0/HSIC, USB 3.1 Gen 1, USB Power Delivery (USB-PD), USB SSIC

Order number 1801.7083.02

Description

Trigger & decode package "MIPI M-PHY, D-PHY": MIPI D-PHY, MIPI M-PHY, UniPro, decoding for DSI und CSI-2

Order number 1801.7090.02

Description

"PCI Express" trigger and decode package : 8b10b (up to 6.25 Gbit/s), PCI Express revision 1.x/2.x

R&S®RTO6-TDBDL

Order number 1801.7725.02

Description

Trigger and decode bundle: Unlocks trigger and decode functionality for all protocols included in R&S®RTO6-K500/-K510/-K520/-K530/-K540/-K550/-K560/-K570/-K580/-K590

Compliance tests
Product
Description

Order number 1801.6912.02

Description

USB 2.0 compliance test

Order number 1801.6929.02

Description

10M/100M/1G-BASE-T/EE Ethernet compliance test

Order number 1801.6935.02

Description

Ethernet compliance test (2.5/5/10GBASE-T)

Order number 1801.6941.02

Description

IEEE 100BASE-T1 compliance test

Order number 1801.6958.02

Description

MIPI-D-PHY compliance test

Order number 1803.6578.02

Description

R&S®MIPI D-PHY compliance test software, V2.5

Order number 1801.6964.02

Description

PCI Express 1.1/2.0 compliance test

Order number 1801.6970.02

Description

IEEE 1000BASE-T1 compliance test

Order number 1801.6987.02

Description

IEEE 10BASE-T1 compliance test

Order number 1801.7890.02

Description

MGBASE-T1 compliance test

Order number 1801.6993.02

Description

DDR3/DDR3L/LPDDR3 signal integrity debug and compliance test

Order number 1801.7160.02

Description

eMMC compliance test

Order number 1801.7690.02

Description

R&S®ScopeSuite automation

Vector signal analysis
Product
Description

Order number 1801.6812.02

Description

I/Q software interface: Converts modulated signals to I/Q data for further processing

Order number 1345.1011.06

Description

Software

Brings the experience and power of Rohde & Schwarz signal analysis to PC and cloud

R&S®FSPC

Order number 1310.0002K02

Description

License dongle

R&S®VSE-K6

Order number 1320.7516.06

Description

Pulse measurements application

R&S®VSE-K6A

Order number 1345.1286.06

Description

Multi-channel pulse measurements

R&S®VSE-K7

Order number 1320.7539.06

Description

Analog modulation analysis (AM/FM/φM)

Modulation analysis for AM/FM/φM modulated single carriers

R&S®VSE-K8

Order number 1345.1970.06

Description

Bluetooth® BR/EDR/LE measurements

R&S®VSE-K10

Order number 1320.7574.06

Description

GSM measurements

GSM/EDGE/ EDGE Evolution

R&S®VSE-K60

Order number 1320.7868.06

Description

Transient measurements

Transient analysis

R&S®VSE-K60H

Order number 1320.7880.06

Description

Transient hop measurements

Transient analysis, requires R&S®VSE-K60

R&S®VSE-K60C

Order number 1320.7874.06

Description

Transient chirp measurements

Transient analysis, requires R&S®VSE-K60

R&S®VSE-K60P

Order number 1345.2230.06

Description

Transient phase noise measurements

R&S®VSE-K70

Order number 1320.7522.06

Description

Vector signal analysis

R&S®VSE-K70M

Order number 1345.1211.06

Description

Multi-modulation analysis

R&S®VSE-K70 option required

R&S®VSE-K70P

Order number 1345.1228.06

Description

BER PRBS measurements

R&S®VSE-K70 option required

R&S®VSE-K72

Order number 1320.7580.06

Description

3GPP FDD measurements

WCDMA signal analysis

R&S®VSE-K91

Order number 1320.7597.06

Description

IEEE 802.11a/b/g measurements

WLAN signal analysis

R&S®VSE-K91P

Order number 1320.7680.02

Description

IEEE 802.11p measurements

WLAN signal analysis

R&S®VSE-K91N

Order number 1320.7600.06

Description

IEEE 802.11n measurements

WLAN signal analysis

R&S®VSE-K91AC

Order number 1320.7616.06

Description

IEEE 802.11ac measurements

WLAN signal analysis

R&S®VSE-K91AX

Order number 1345.1411.06

Description

IEEE 802.11ax measurements

WLAN signal analysis

R&S®VSE-K96

Order number 1320.7922.06

Description

OFDM signal analysis

R&S®VSE-K100

Order number 1320.7545.06

Description

EUTRA/LTE FDD uplink and downlink measurement application

LTE signal analysis

R&S®VSE-K102

Order number 1320.7551.06

Description

EUTRA/LTE advanced and MIMO (downlink)

LTE signal analysis

R&S®VSE-K104

Order number 1320.7568.06

Description

EUTRA/LTE TDD uplink and downlink measurement application

LTE signal analysis

R&S®VSE-K106

Order number 1320.7900.06

Description

EUTRA/LTE

Narrowband IoT analysis

R&S®VSE-K144

Order number 1309.9574.06

Description

5G NR uplink and downlink measurement application

R&S®VSE-K146

Order number 1345.1305.06

Description

5G MIMO measurements

R&S®VSE-K148

Order number 1345.1392.06

Description

5G NR R16 measurements

R&S®VSE-K149

Order number 1345.1463.06

Description

HRP UWB measurements

R&S®VSE-K171

Order number 1345.1663.02

Description

5G NR R17 measurements

R&S®VSE-K175

Order number 1350.7020.06

Description

O-RAN measurements

R&S®VSE-K201

Order number 1345.2001.06

Description

OneWeb reverse link measurement application for R&S®VSE software. This application can be used to analyze OneWeb SC-FDMA signals.

R&S®VSE-K544

Order number 1309.9580.06

Description

User-defined Frequency Correction by SnP File

R&S®VSE-SWM

Order number 1320.7622.81

Description

Software maintenance

General
Product
Description
R&S®RTO6-Z1

Order number 1801.6641.02

Description

Front Cover: Protects the front of the R&S®RTO6 oscilloscope

R&S®RTO6-Z3

Order number 1801.6658.02

Description

Soft Case: Stores the R&S®RTO6 oscilloscope and accessories

R&S®RTO6-Z4

Order number 1801.6712.02

Description

Transit case: Protects the R&S®RTO6 oscilloscope and accessories during transport

R&S®ZZA-RTO6

Order number 1801.6729.02

Description

19" rackmount kit

Test fixtures
Product
Description
R&S®RT-ZF1

Order number 1317.3420.02

Description

Test fixture set for USB2.0 compliance

Test fixture for USB 1.0/1.1/2.0 compliance tests. Supported by R&S®RTO-K21 USB compliance test option.

R&S®RT-ZF2

Order number 1317.5522.02

Description

Test fixture for 10/100/1000BASE-T, 10G-BaseT and BroadR-Reach Ethernet

Supported by R&S®RTO-K22, R&S®RTO-K23 and R&S®RTO-K24 Ethernet compliance test options.

R&S®RT-ZF3

Order number 5025.0670.02

Description

Frequency converter

for 100BASE-T1/BroadR-Reach compliance test

R&S®RT-ZF4

Order number 1333.0880.02

Description

10BASE-TE Energy Efficient Ethernet Test Fixture

R&S®RT-ZF5

Order number 1333.0896.02

Description

Ethernet Probing Fixture

(directional, link partner, load)

R&S®RT-ZF6

Order number 1337.8579.02

Description

Frequency converter board

for 1000BASE-T1 compliance test

R&S®RT-ZF7

Order number 1801.3688.02

Description

Automotive T&D Fixture

Automotive Ethernet probing fixture including 2 SMA adapters RT-ZF7A

R&S®RT-ZF7A

Order number 1801.4126.02

Description

SMA Adapter

High precision adapter board from automotive connector to SMA

R&S®RT-ZF7P

Order number 1802.9680.02

Description

SMA adapter for PoDL

High precision adapter board from Industrial Ethernet connectors to SMA

R&S®RT-ZF8

Order number 1801.3694.02

Description

Automotive Ethernet Compliance Fixture

Test fixture for 100BASE-T1 and 1000BASE-T1 compliance testing according to IEEE and OPEN TC8

R&S®RT-ZF2C

Order number 1317.5639.02

Description

1000BASE-T Jitter Test Cable

1000Base-T jitter test cable for the R&S®RTO-K22 Ethernet compliance test solution.

Order number 1800.0004.02

Description

Power deskew fixture

Deskew fixture for voltage and current probes for power measurements; includes USB 2.0 cable for power supply

Passive probes
Product
Description

Order number 1409.7550.00

Description

Passive probe, 500 MHz, 10:1

Passive broadband probes
Product
Description

Order number 1409.7608.02

Description

Transmission line probe, 8 GHz, passive

Active single-ended probes
Product
Description

Order number 1418.7007.02

Description

Active single-ended probe, 1 GHz, Rohde & Schwarz probe interface

Order number 1410.4080.02

Description

Active single-ended probe, 1 GHz, R&S®ProbeMeter, Rohde & Schwarz probe interface

Order number 1410.3502.02

Description

Active single-ended probe, 1.5 GHz, R&S®ProbeMeter, Rohde & Schwarz probe interface

Order number 1410.4309.02

Description

Active single-ended probe, 3 GHz, R&S®ProbeMeter, Rohde & Schwarz probe interface

Order number 1418.7307.02

Description

Active single-ended probe, 6 GHz, R&S®ProbeMeter, Rohde & Schwarz probe interface

Active differential probes
Product
Description

Order number 1410.4715.02

Description

Active differential probe, 1 GHz, Rohde & Schwarz probe interface

Order number 1410.4409.02

Description

Active differential probe, 1.5 GHz, Rohde & Schwarz probe interface

Order number 1410.4609.02

Description

Active differential probe, 3.0 GHz, Rohde & Schwarz probe interface

Order number 1410.5205.02

Description

Active differential probe, 4.5 GHz, Rohde & Schwarz probe interface

Modular probe system
Product
Description

Order number 1800.4700.02

Description

Modular probe amplifier module, 1.5 GHz

Order number 1419.3005.02

Description

Modular probe amplifier module, 3 GHz

Order number 1419.3105.02

Description

Modular probe amplifier module, 6 GHz

Order number 1419.3205.02

Description

Modular probe amplifier module, 9 GHz

Power rail probes
Product
Description

Order number 1800.5006.02

Description

Power rail probe, 2 GHz, R&S®ProbeMeter, Rohde & Schwarz probe interface

2.0 GHz, 1:1, 50 kΩ, R&S probe interface

Order number 1800.5406.02

Description

Power rail probe, 4 GHz, R&S®ProbeMeter, Rohde & Schwarz probe interface

Multi-channel power probes
Product
Description

Order number 1326.0259.02

Description

Multi-channel power probe

1 MHz, 5 MSa/s, 18 Bit, 2 current inputs, 2 voltage inputs

Order number 1326.0259.04

Description

Multi-channel power probe

1 MHz, 5 MSa/s, 18 Bit, 4 current inputs, 4 voltage inputs

High voltage probes
Product
Description

Order number 1333.0873.02

Description

250 MHz passive high voltage probe

Order number 1409.7720.02

Description

400 MHz passive high voltage probe

Order number 1409.7737.02

Description

400 MHz passive high voltage probe

Order number 1800.2107.02

Description

100 MHz High voltage differential probe

Order number 1800.2207.02

Description

200 MHz High voltage differential probe

Order number 1800.2007.02

Description

100 MHz High voltage differential probe

Current probes
Product
Description

Order number 1333.0850.02

Description

AC/DC 20 kHz current probe

Order number 1333.0844.02

Description

100 kHz current probe

Order number 1409.7750K02

Description

10 MHZ current probe

Order number 1409.8210.02

Description

10 MHZ Current probe

Order number 1409.8227.02

Description

50 MHZ Current probe

Order number 1409.7766K02

Description

100 MHZ current probe

Order number 1409.8233.02

Description

100 MHZ current probe

Order number 1409.7772K02

Description

120 MHz current probe

Order number 1801.4932.02

Description

120 MHz current probe

EMC near field probes
Product
Description

Order number 1147.2736.02

Description

E and H near-field probe set

R&S®RTO6 Mediacenter

CES: Ultra-Wideband Device Testing

31-Jan-2022

1000BASE-T1 automotive Ethernet compliance test with Test Mode 4

28-Dec-2021

1000BASE-T1 interoperability test

22-Dec-2021

R&S®RTO6 series brings a new user interface for straightforward workflows

01-Jul-2021

Get an impression of the R&S®RTO6

01-Jul-2021

Application videos

Embedding & Equalization with the R&S RTP Oscilloscope (Part 1)

11-Jul-2024

Embedding & Equalization with the R&S RTP Oscilloscope (Part 2)

10-Jul-2024

Embedding & Equalization with the R&S RTP Oscilloscope (Part 3)

09-Jul-2024

Embedding & Equalization with the R&S RTP Oscilloscope (Part 4)

08-Jul-2024

PAM-N Analysis with the R&S RTP Oscilloscope (Part 1)

28-Jun-2024

PAM-N Analysis with the R&S RTP Oscilloscope (Part 2)

27-Jun-2024

PAM-N Analysis with the R&S RTP Oscilloscope (Part 3)

26-Jun-2024

O-RU energy efficiency testing

12-Mar-2024

Also interesting for you

Premium content: Scopefield – A city with R&S®RTO6 applications

More information

10 years of Rohde & Schwarz oscilloscope innovation

More information

Oscilloscopes promotion

Save up to 46% on fully equipped oscilloscopes. All options included from the start. Save now.

More information

Oscilloscope webinar center for digital design and power electronics applications

More information

Request information

Do you have questions or need additional information? Simply fill out this form and we will get right back to you.

Marketing permission

Your request has been sent successfully. We will contact you shortly.
An error is occurred, please try it again later.
General and legal information

Manufacturer's recommended retail price (MSRP). The price shown does not include VAT. Prices and offers are only intended for entrepreneurs and not for private end consumers.

You may use the electronic signature via DocuSign to submit your information to enroll with the Rohde & Schwarz Customer Delegated Administration program. DocuSign processes the information provided according to their . The minimum system requirements for using the DocuSign system may change over time. The current system requirements are found

Terms & Conditions of the Prize Draw 10 years Rohde & Schwarz oscilloscopes

1. The prize draw “10 years Rohde & Schwarz oscilloscopes” (herein referred to as “Draw”) is organized by Rohde & Schwarz GmbH & Co. KG, Mühldorfstraße 15, 81671 Munich, Germany, Tel. +49 89 41 29 0 (herein referred to as “R&S).

2. All participators can register to the draw during January 01, 2020 to December 31, 2020 with their name, company name and business e-mail.

3. Participation is free of charge and not dependent on the purchase of goods or services.

4. The draw is only open to legal entities and only the legal entities are able to win the prizes. An individual person is not allowed to participate on its own name and its own account but as a representative of a legal entity filing the participation form in the name of and on behalf of the legal entity.

5. The prizes to win are 1 of 10 R&S®RTB2000 within the time frame January 1, 2020 to December 31, 2020:

Prize: 1x R&S®RTB2000 Digital Oscilloscope

6. The draw takes place at Rohde & Schwarz headquarters, Muehldorstrasse 15, 81671 Munich. The winner of the prizes will be informed by e-mail within 5 (5) working days.

7. The authorized representative of the legal entity shall inform Rohde & Schwarz about the acceptance of the price. In case of the denial of the acceptance, or no answer within two (2) weeks, a new winner will be drawn. If no winner can be determined within four (4) weeks, the draw ends and the prize forfeit.

8. R&S’ employees and members of their families and also person being familiar with the process of the draw and members of their families are excluded from filling the participation form.

9. No cash equivalent or exchange of prizes is allowed. Prizes are non-transferable. All taxes, levies, duties, fees and other charges levied in the participant´s country shall be borne by the participant.

10. Personal data will be processed only for the purpose of this prize draw and deleted four (4) weeks after the draw, if not agreed otherwise.

11. Any Participant who does not comply with these Terms & Conditions may be disqualified by R&S from this Competition. In such cases, prizes can also be withdrawn retrospectively. In case a prize is withdrawn retrospectively due to the non-compliance with these Terms & Conditions, it shall be returned by the respective participant at his cost to R&S’ address mentioned under Nr.1 and a new winner will be drawn.

12. The participants cannot claim the prizes of this draw and no legal recourse is permitted in this respect.

13. The draw and any contractual relationship arising therefrom between R&S and the respective participant shall be governed by and construed in accordance with the laws of Germany, without any recourse to the conflict of laws. The courts of Munich, Germany, shall have exclusive jurisdiction in case of any disputes arising directly or indirectly from the participation in this Competition.

* “fast delivery” inside 7 working days applies to the Rohde & Schwarz in-house procedures from order processing through to available ex-factory to ship.
