Key facts
- Bandwidth: 60 MHz to 500 MHz
- Sample rate: up to 5 Gsample/s
- Memory depth: up to 500 kpts, 50 Mpts segmented memory
- ADC resolution: 10-bit
- Isolated channels (CAT IV 600 V (RMS) / CAT III 1000 V (RMS))
Starting at 3 560 EUR
Key facts
Starting at 3 560 EUR
When debugging embedded devices in the lab or analyzing complex problems in the field, the R&S®Scope Rider offers the performance and capabilities of a lab oscilloscope as well as the form factor and ruggedness of a battery-operated handheld device. Isolated channels combined with 500 MHz bandwidth makes it a perfect choice for power electronics applications. An integrated multimeter (two-channel model) or a multimeter mode (four-channel model) make the instrument the perfect tool for troubleshooting all kinds of electronics problems.
Vertical system | ||
Analog channels | R&S®RTH1002 R&S®RTH1012/R&S®RTH1022 R&S®RTH1032/R&S®RTH1052 | 2 |
R&S®RTH1004/R&S®RTH1014/R&S®RTH1024/R&S®RTH1034/R&S®RTH1054 | 4 | |
Digital channels (opt.) | 8 | |
Bandwidth (-3 dB) | R&S®RTH1002 and R&S®RTH1004 R&S®RTH1012 and R&S®RTH1014 R&S®RTH1022 and R&S®RTH1024 R&S®RTH1032 and R&S®RTH1034 R&S®RTH1052 and R&S®RTH1054 | 60 MHz, 100 MHz, 200 MHz, 350 MHz, 500 MHz |
Rise time | R&S®RTH1002 and R&S®RTH1004 R&S®RTH1012 and R&S®RTH1014 R&S®RTH1022 and R&S®RTH1024 R&S®RTH1032 and R&S®RTH1034 R&S®RTH1052 and R&S®RTH1054 | 60 MHz, <5.8 ns 100 MHz, <3.5 ns 200 MHz, <1.75 ns 350 MHz, <1 ns 500 MHz, <700 ps |
Input impedance | 1 MΩ ± 1 % || 12 pF ± 2 pF (meas.) | |
Input sensitivity | 2 mV/div to 100 V/div | |
ADC resolution | 10 bit | |
Offset range | +/-200 V | |
Maximum input voltage | CAT IV 300 V (RMS), 424 V (Vp) CAT IV 600 V, CAT III 1000 V | |
Acquisition system | ||
Realtime sampling rate | 1/2/4 channels active | 5/2.5/1.25 Gsample/s |
Acquisition memory | 1/2/4 channels active | 500/250/125 ksample/channel |
Max. acquisition rate | 50,000 waveforms/s | |
Decimation modes | sample, high resolution, peak detect | |
Waveform arithmetics | envelope, average | |
Horizontal system | ||
Timebase range | 1 ns/div to 500 s/div | |
Accuracy (after delivery/calibration) | ±10 ppm | |
Channel deskew | ±100 ns | |
Trigger system | ||
Standard Trigger types | edge, glitch, width | |
Optional Trigger types | TV/Video, pattern, state, runt, slew rate, window, Data2clock, serial pattern, timeout, interval, protocol | |
Analysis and measurement functions | ||
Automatic measurements | 37 measurement functions | |
Mask testing | ||
Mask definition | tolerance tube | |
Actions on violation | none, beep, stop | |
History and segmented memory | ||
Number of segments | up to 5000 | |
Protocol trigger and decode | ||
Supported protocols | (optional: R&S®RTH-K1, R&S®RTH-K2, R&S®RTH-K3, R&S®RTH-K9, R&S®RTH-K10) | I2C, UART/RS-232/RS-422/RS-485, CAN, LIN, CAN-FD, SENT |
Logic analyzer (MSO) functionality | ||
Digital input channels | 8 | |
General data | ||
Dimensions | W x H x D | 201 mm x 293 mm x 74 mm (7.91 in x 11.54 in x 2.91 in) |
Weight | with battery | 2.4 kg (5.3 lb) (nom.) |
Display | 7.0" LC TFT 800 x 480 color display | |
Interfaces | USB host, USB device, LAN, wireless LAN (optional) | |
Operating system | Embedded | |
Data logger | ||
Number of simult. logging channels | 4 | |
Measurement speed | 1/2/5 measurements/s | |
Memory depth | 2 Msample per logging channel | |
Digital voltmeter/digital multimeter | ||
Resolution | 2-channel version (digital multimeter): 11 000 counts 4-channel version (digital voltmeter): 999 counts | |
Voltage and current | current with optional current probe or shunt | DC, AC, AC+DC |
Temperature | with PT100 temperature sensor | |
IP rating | IP51, in line with IEC 60529 |
Manufacturer's recommended retail price (MSRP). The price shown does not include VAT. Prices and offers are only intended for entrepreneurs and not for private end consumers.
