Key Facts
- 6 GHz maximum bandwidth
- 1 million waveforms per second
- 9.4 ENOB for ultimate signal integrity
- 2 Gpoints maximum memory
- Exclusive frequency zone trigger
A partire da 0 EUR
Key Facts
A partire da 0 EUR
The R&S®RTO6 is the oscilloscope you can trust. Engineered to deliver reliable results, it acts as a sophisticated laboratory companion to solve measurement problems fast and keep you on schedule. The R&S®RTO6 oscilloscope series leverages the engineer’s expertise and builds your measurement confidence by achieving deep insights, whenever needed.
The R&S®RTO6 oscilloscope series provides superior signals to insight for your applications. The large 15.6" touchscreen and a new GUI, combined with high waveform update rate, excellent signal fidelity, digital trigger and deep responsive memory serve as a fully integrated test solution for frequency, protocol and logic analysis. The R&S®RTO6 oscilloscope series’ rich measurement toolset combined with a streamlined user interface helps you quickly solve circuit issues from simple to complex.
Quick Links
... with an unparalleled update rate
... with excellent signal integrity
... with up to 16 bit resolution
... with advanced trigger capabilities
... with deep and responsive memory
Vertical system | ||
Analog channels | 4 | |
Bandwidth (-3 dB) | R&S®RTO64 with R&S®RTO6-B90 option | 600 MHz |
(one bandwidth option mandatory) | R&S®RTO64 with R&S®RTO6-B91 option | 1 GHz |
R&S®RTO64 with R&S®RTO6-B92 option | 2 GHz | |
R&S®RTO64 with R&S®RTO6-B93 option | 3 GHz | |
R&S®RTO64 with R&S®RTO6-B94 option | 4 GHz | |
R&S®RTO64 with R&S®RTO6-B96 option | on 2 channels: 6 GHz on 4 channels: 4 GHz |
|
Rise time | R&S®RTO64 with R&S®RTO6-B90 option | 635 ps |
R&S®RTO64 with R&S®RTO6-B91 option | 375 ps | |
R&S®RTO64 with R&S®RTO6-B92 option | 210 ps | |
R&S®RTO64 with R&S®RTO6-B93 option | 145 ps | |
R&S®RTO64 with R&S®RTO6-B94 option | 110 ps | |
R&S®RTO64 with R&S®RTO6-B96 option | 77 ps | |
Vertical resolution | 16-bit system architecture | |
Effective number of bits / ENOB (meas.) | at 50 Ω, 50 mV/div, 10 MHz input signal with 90 % full-scale 50 MHz 100 MHz 200 MHz 300 MHz 500 MHz 1 GHz 2 GHz 4 GHz 6 GHz |
9.4 9.0 8.6 8.2 8.1 7.7 7.1 6 6 |
RMS noise floor | at 50 Ω, 1 mV/div, 10 MHz bandwidth filter | 10 µV (meas.) |
Input impedance | 50 Ω ±1.5 % 1 MΩ ±1 % at 15 pF (meas.) |
|
Input sensitivity | max. bandwidth in all ranges | 50 Ω: 1 mV/div to 1 V/div 1 MΩ: 1 mV/div to 10 V/div |
Acquisition system | ||
Realtime sampling rate | R&S®RTO6-B90, R&S®RTO6-B91, R&S®RTO6-B92, R&S®RTO6-B93 options | max 10 Gsample/s on each channel |
R&S®RTO6-B94, R&S®RTO6-B96 options | max. 10 Gsample/s on 4 channels max. 20 Gsample/s on 2 channels |
|
Acquisition memory | standard | 200 Mpoints on 4 channels 400 Mpoints on 2 channels 800 Mpoints on 1 channel |
R&S®RTO6-B104 option | 400 Mpoints on 4 channels 800 Mpoints on 2 channels 800 Mpoints on 1 channel |
|
R&S®RTO6-B110 option | 1 Gpoint on 4 channels 2 Gpoints on 2 channels (restriction: 1 Gpoint on 2 channels when channel 1 and channel 2 or channel 3 and channel 4 are turned on) 2 Gpoints on 1 channel |
|
Max. acquisition rate | 1 000 000 waveforms/s | |
Decimation modes | any combination of decimation mode and waveform arithmetics on up to 3 waveforms per channel | sample, peak detect, high resolution, root mean square |
Waveform arithmetics | off, envelope, average | |
Interpolation modes | linear, sin(x)/x, sample&hold | |
Deembedding (optional) | yes | |
Horizontal system | ||
Timebase range | 25 ps/div to 10,000 s/div | |
Timebase Accuracy | after delivery/calibration | ±10 ppb |
Trigger system | ||
Standard Trigger types | edge, glitch, width, runt, window, timeout, interval, slew rate, data2clock, pattern, state, serial pattern, TV/video, zone trigger | |
Optional Trigger types | serial bus trigger | |
Trigger sensitivity | definition of trigger hysteresis | automatic or manually adjustable from 0 div to 5 div |
Analysis and measurement | ||
Automatic measurements | 47 | |
Cursor measurements | 4 | |
Waveform mathematics | advanced (formula editor) | |
Mask testing | ||
Mask definition | advanced (user-configurable, hardware based) | |
Logic analyzer (MSO) functionality | ||
Digital input channels | 16 | |
MSO Memory depth | 200 Mpts per channel | |
MSO Bandwidth | 400 MHz | |
MSO sampling rate | 5 Gsample/s per channel | |
General data | ||
Dimensions | W x H x D | 450 mm × 315 mm × 204 mm (17.72 in × 12.40 in × 8.03 in) |
Weight | 10.7 kg (23.59 lb) | |
Interfaces | 1 Gbps LAN, type A: 2 x USB 3.1, 2 x USB 2.0, type B: 1 x USB 3.1, GPIB (optional), HDMI and DisplayPort for external monitor, external trigger, trigger output | |
Display | 15.6" capacitive touchscreen, resolution: 1920 x 1080 pixel (Full HD) | |
Operating system | Windows |
Order Number 1801.6741.02
Mixed signal option: 16 digital channels, 5 GSa/s, 400 MHz bandwidth
Order Number 1801.6735.02
Digital Extension Port for R&S®RTO6. Required for R&S®RT-ZVC02 and R&S®RT-ZVC04 Hardware. Included in R&S®RTO-B1.
Order Number 1801.6758.02
Arbitrary waveform generator: 2-channel 500 MSample/s waveform generator and 8-channel pattern generator
Order Number 1801.6764.02
Differential 16 GHz pulse source for R&S®RTO6 Oscilloscope
Contains an accessory bag with 2 SMA cables, 4 SMA terminations, 2 SMA(f) to SMA(f) adapters, 2 SMA shorts and 1 ESD wrist strap with grounding cord.
Order Number 1801.6770.02
GPIB Interface
Order Number 1801.6787.02
Replacement SSD, pre-installed with OS and oscilloscope firmware
Order Number 1801.6793.02
Memory upgrade to 400 Mpoints on 4 channels, 800 Mpoints on 2 channels
Order Number 1801.6806.04
Memory upgrade to 1 Gpoints on 4 channels, 2 Gpoints on 2 channels
Order Number 1801.7277.02
Upgrade of the R&S®RTO6-B90 option to 1 GHz bandwidth
Order Number 1801.7283.02
Upgrade of the R&S®RTO6-B90 option to 2 GHz bandwidth
Order Number 1801.7290.02
Upgrade of the R&S®RTO6-B90 option to 3 GHz bandwidth
Order Number 1801.7302.02
Upgrade of the R&S®RTO6-B90 option to 4 GHz bandwidth
Order Number 1801.7319.02
Upgrade of the R&S®RTO6-B90 option to 6 GHz bandwidth
Order Number 1801.7325.02
Upgrade of the R&S®RTO6-B91 option to 2 GHz bandwidth
Order Number 1801.7331.02
Upgrade of the R&S®RTO6-B91 option to 3 GHz bandwidth
Order Number 1801.7348.02
Upgrade of the R&S®RTO6-B91 option to 4 GHz bandwidth
Order Number 1801.7354.02
Upgrade of the R&S®RTO6-B91 option to 6 GHz bandwidth
Order Number 1801.7360.02
Upgrade of the R&S®RTO6-B92 option to 3 GHz bandwidth
Order Number 1801.7377.02
Upgrade of the R&S®RTO6-B92 option to 4 GHz bandwidth
Order Number 1801.7383.02
Upgrade of the R&S®RTO6-B92 option to 6 GHz bandwidth
Order Number 1801.7390.02
Upgrade of the R&S®RTO6-B93 option to 4 GHz bandwidth
Order Number 1801.7402.02
Upgrade of the R&S®RTO6-B93 option to 6 GHz bandwidth
Order Number 1801.7419.02
Upgrade of the R&S®RTO6-B94 option to 6 GHz bandwidth
Order Number 1801.6829.02
Jitter analysis
Order Number 1801.6835.02
Clock data recovery
Order Number 1801.6858.02
Power analysis
Order Number 1801.6870.02
Spectrum analysis
Order Number 1803.6778.02
Python interface for user defined math
Order Number 1801.6887.02
Deembedding for compensation of channel effects
Order Number 1801.8109.02
Embedding & Equalization
Embedding user-configurable components, predistortion at TX and equalization at RX via CTLE, FFE or DFE
Order Number 1801.6893.02
TDR/TDT analysis
Order Number 1801.6906.02
Jitter decomposition: Decomposition of jitter components, display of step response, histograms, synthetic eye diagrams, spectrum and BER-bathtub curve
Order Number 1801.7677.02
Jitter and noise decomposition
Order Number 1801.8050.02
PAM-N Analysis
Enabled for advanced jitter & noise, advanced eye and selected automated time/amplitude and eye measurements.
Order Number 1801.8080.02
Advanced Eye Analysis
Including SW-CDR and comprehensive Mask test library.
Order Number 1801.6864.02
Bus analysis: Bus measurements and analysis functions
Order Number 1801.7019.02
Trigger & decode package "Low speed serial buses": I2C, SPI, RS-232, UART, I2S, LJ, RJ, TDM, Manchester, NRZ
Order Number 1801.7025.02
Trigger & decode package "Automotive protocols": CAN incl. CAN-dbc file import, CAN-FD, LIN, FlexRay™ incl.
Fibex file import, SENT, CXPI
Order Number 1801.7031.02
Trigger & decode package "Aerospace protocols": MIL-STD-1553, ARINC 429, SpaceWire
Order Number 1801.7048.02
Ethernet protocols trigger and decode package: 10BASE-T, 100BASE-TX, MDIO
Order Number 1801.7054.02
Trigger & decode MIPI RFFE
Order Number 1801.7060.02
Trigger & decode package "Automotive Ethernet": IEEE 100BASE-T1, IEEE 1000BASE-T1
Order Number 1801.7077.02
Trigger & decode package "USB protocols": USB 1.0/1.1, USB 2.0/HSIC, USB 3.1 Gen 1, USB Power Delivery (USB-PD), USB SSIC
Order Number 1801.7083.02
Trigger & decode package "MIPI M-PHY, D-PHY": MIPI D-PHY, MIPI M-PHY, UniPro, decoding for DSI und CSI-2
Order Number 1801.7090.02
"PCI Express" trigger and decode package : 8b10b (up to 6.25 Gbit/s), PCI Express revision 1.x/2.x
Order Number 1801.7725.02
Trigger and decode bundle: Unlocks trigger and decode functionality for all protocols included in R&S®RTO6-K500/-K510/-K520/-K530/-K540/-K550/-K560/-K570/-K580/-K590
Order Number 1801.6912.02
USB 2.0 compliance test
Order Number 1801.6929.02
10M/100M/1G-BASE-T/EE Ethernet compliance test
Order Number 1801.6935.02
Ethernet compliance test (2.5/5/10GBASE-T)
Order Number 1801.6941.02
IEEE 100BASE-T1 compliance test
Order Number 1801.6958.02
MIPI-D-PHY compliance test
Order Number 1803.6578.02
R&S®MIPI D-PHY compliance test software, V2.5
Order Number 1801.6964.02
PCI Express 1.1/2.0 compliance test
Order Number 1801.6970.02
IEEE 1000BASE-T1 compliance test
Order Number 1801.6987.02
IEEE 10BASE-T1 compliance test
Order Number 1801.7890.02
MGBASE-T1 compliance test
Order Number 1801.6993.02
DDR3/DDR3L/LPDDR3 signal integrity debug and compliance test
Order Number 1801.7160.02
eMMC compliance test
Order Number 1801.7690.02
R&S®ScopeSuite automation
Order Number 1801.6812.02
I/Q software interface: Converts modulated signals to I/Q data for further processing
Order Number 1345.1011.06
Software
Brings the experience and power of Rohde & Schwarz signal analysis to PC and cloud
Order Number 1310.0002K02
License dongle
Order Number 1320.7516.06
Pulse measurements application
Order Number 1345.1286.06
Multi-channel pulse measurements
Order Number 1320.7539.06
Analog modulation analysis (AM/FM/φM)
Modulation analysis for AM/FM/φM modulated single carriers
Order Number 1345.1970.06
Bluetooth® BR/EDR/LE measurements
Order Number 1320.7574.06
GSM measurements
GSM/EDGE/ EDGE Evolution
Order Number 1320.7868.06
Transient measurements
Transient analysis
Order Number 1320.7880.06
Transient hop measurements
Transient analysis, requires R&S®VSE-K60
Order Number 1320.7874.06
Transient chirp measurements
Transient analysis, requires R&S®VSE-K60
Order Number 1345.2230.06
Transient phase noise measurements
Order Number 1320.7522.06
Vector signal analysis
Order Number 1345.1211.06
Multi-modulation analysis
R&S®VSE-K70 option required
Order Number 1345.1228.06
BER PRBS measurements
R&S®VSE-K70 option required
Order Number 1320.7580.06
3GPP FDD measurements
WCDMA signal analysis
Order Number 1320.7597.06
IEEE 802.11a/b/g measurements
WLAN signal analysis
Order Number 1320.7680.02
IEEE 802.11p measurements
WLAN signal analysis
Order Number 1320.7600.06
IEEE 802.11n measurements
WLAN signal analysis
Order Number 1320.7616.06
IEEE 802.11ac measurements
WLAN signal analysis
Order Number 1345.1411.06
IEEE 802.11ax measurements
WLAN signal analysis
Order Number 1320.7922.06
OFDM signal analysis
Order Number 1320.7545.06
EUTRA/LTE FDD uplink and downlink measurement application
LTE signal analysis
Order Number 1320.7551.06
EUTRA/LTE advanced and MIMO (downlink)
LTE signal analysis
Order Number 1320.7568.06
EUTRA/LTE TDD uplink and downlink measurement application
LTE signal analysis
Order Number 1320.7900.06
EUTRA/LTE
Narrowband IoT analysis
Order Number 1309.9574.06
5G NR uplink and downlink measurement application
Order Number 1345.1305.06
5G MIMO measurements
Order Number 1345.1392.06
5G NR R16 measurements
Order Number 1345.1463.06
HRP UWB measurements
Order Number 1345.1663.02
5G NR R17 measurements
Order Number 1350.7020.06
O-RAN measurements
Order Number 1345.2001.06
OneWeb reverse link measurement application for R&S®VSE software. This application can be used to analyze OneWeb SC-FDMA signals.
Order Number 1309.9580.06
User-defined Frequency Correction by SnP File
Order Number 1320.7622.81
Software maintenance
Order Number 1801.6641.02
Front Cover: Protects the front of the R&S®RTO6 oscilloscope
Order Number 1801.6658.02
Soft Case: Stores the R&S®RTO6 oscilloscope and accessories
Order Number 1801.6712.02
Transit case: Protects the R&S®RTO6 oscilloscope and accessories during transport
Order Number 1801.6729.02
19" rackmount kit
Order Number 1317.3420.02
Test fixture set for USB2.0 compliance
Test fixture for USB 1.0/1.1/2.0 compliance tests. Supported by R&S®RTO-K21 USB compliance test option.
Order Number 1317.5522.02
Test fixture for 10/100/1000BASE-T, 10G-BaseT and BroadR-Reach Ethernet
Supported by R&S®RTO-K22, R&S®RTO-K23 and R&S®RTO-K24 Ethernet compliance test options.
Order Number 5025.0670.02
Frequency converter
for 100BASE-T1/BroadR-Reach compliance test
Order Number 1333.0880.02
10BASE-TE Energy Efficient Ethernet Test Fixture
Order Number 1333.0896.02
Ethernet Probing Fixture
(directional, link partner, load)
Order Number 1337.8579.02
Frequency converter board
for 1000BASE-T1 compliance test
Order Number 1801.3688.02
Automotive T&D Fixture
Automotive Ethernet probing fixture including 2 SMA adapters RT-ZF7A
Order Number 1801.4126.02
SMA Adapter
High precision adapter board from automotive connector to SMA
Order Number 1802.9680.02
SMA adapter for PoDL
High precision adapter board from Industrial Ethernet connectors to SMA
Order Number 1801.3694.02
Automotive Ethernet Compliance Fixture
Test fixture for 100BASE-T1 and 1000BASE-T1 compliance testing according to IEEE and OPEN TC8
Order Number 1317.5639.02
1000BASE-T Jitter Test Cable
1000Base-T jitter test cable for the R&S®RTO-K22 Ethernet compliance test solution.
Order Number 1800.0004.02
Power deskew fixture
Deskew fixture for voltage and current probes for power measurements; includes USB 2.0 cable for power supply
Order Number 1409.7550.00
Passive probe, 500 MHz, 10:1
Order Number 1409.7608.02
Transmission line probe, 8 GHz, passive
Order Number 1418.7007.02
Active single-ended probe, 1 GHz, Rohde & Schwarz probe interface
Order Number 1410.4080.02
Active single-ended probe, 1 GHz, R&S®ProbeMeter, Rohde & Schwarz probe interface
Order Number 1410.3502.02
Active single-ended probe, 1.5 GHz, R&S®ProbeMeter, Rohde & Schwarz probe interface
Order Number 1410.4309.02
Active single-ended probe, 3 GHz, R&S®ProbeMeter, Rohde & Schwarz probe interface
Order Number 1418.7307.02
Active single-ended probe, 6 GHz, R&S®ProbeMeter, Rohde & Schwarz probe interface
Order Number 1410.4715.02
Active differential probe, 1 GHz, Rohde & Schwarz probe interface
Order Number 1410.4409.02
Active differential probe, 1.5 GHz, Rohde & Schwarz probe interface
Order Number 1410.4609.02
Active differential probe, 3.0 GHz, Rohde & Schwarz probe interface
Order Number 1410.5205.02
Active differential probe, 4.5 GHz, Rohde & Schwarz probe interface
Order Number 1800.4700.02
Modular probe amplifier module, 1.5 GHz
Order Number 1419.3005.02
Modular probe amplifier module, 3 GHz
Order Number 1419.3105.02
Modular probe amplifier module, 6 GHz
Order Number 1419.3205.02
Modular probe amplifier module, 9 GHz
Order Number 1800.5006.02
Power rail probe, 2 GHz, R&S®ProbeMeter, Rohde & Schwarz probe interface
2.0 GHz, 1:1, 50 kΩ, R&S probe interface
Order Number 1800.5406.02
Power rail probe, 4 GHz, R&S®ProbeMeter, Rohde & Schwarz probe interface
Order Number 1326.0259.02
Multi-channel power probe
1 MHz, 5 MSa/s, 18 Bit, 2 current inputs, 2 voltage inputs
Order Number 1326.0259.04
Multi-channel power probe
1 MHz, 5 MSa/s, 18 Bit, 4 current inputs, 4 voltage inputs
Order Number 1333.0873.02
250 MHz passive high voltage probe
Order Number 1409.7720.02
400 MHz passive high voltage probe
Order Number 1409.7737.02
400 MHz passive high voltage probe
Order Number 1800.2107.02
100 MHz High voltage differential probe
Order Number 1800.2207.02
200 MHz High voltage differential probe
Order Number 1800.2007.02
100 MHz High voltage differential probe
Order Number 1333.0850.02
AC/DC 20 kHz current probe
Order Number 1333.0844.02
100 kHz current probe
Order Number 1409.8204.02
2 MHZ current probe
Order Number 1409.7750K02
10 MHZ current probe
Order Number 1409.8210.02
10 MHZ Current probe
Order Number 1409.7766K02
100 MHZ current probe
Order Number 1409.8233.02
100 MHZ current probe
Order Number 1409.7772K02
120 MHz current probe
Order Number 1801.4932.02
120 MHz current probe
Order Number 1147.2736.02
E and H near-field probe set
Manufacturer's recommended retail price (MSRP). The price shown does not include VAT. Prices and offers are only intended for entrepreneurs and not for private end consumers.
You may use the electronic signature via DocuSign to submit your information to enroll with the Rohde & Schwarz Customer Delegated Administration program. DocuSign processes the information provided according to their . The minimum system requirements for using the DocuSign system may change over time. The current system requirements are found
Termini e condizione del Concorso 10 anni di oscilloscopi Rohde & Schwarz
1. Il concorso a premi “10 anni di oscilloscopi Rohde & Schwarz” (di seguito il “Concorso”) è organizzato da Rohde & Schwarz GmbH & Co. KG, Mühldorfstraße 15, 81671 Monaco di Baviera, Germania, Tel. +49 89 41 29 0 (di seguito “R&S).
2. Tutti i partecipanti possono registrarsi al concorso dal 1 gennaio 2020 al 31 dicembre 2020 comunicando il loro nome, azienda e indirizzo e-mail lavorativo.
3. La partecipazione al concorso è gratuita e non è legata all’acquisto di alcun bene o servizio.
4. Il concorso è aperto alle sole persone giuridiche e solo le persone giuridiche potranno vincere i premi. Non è ammessa la partecipazione delle persone fisiche col proprio nome e account, ma un rappresentante di una persona giuridica può compilare il modulo di partecipazione in nome e per conto della persona giuridica.
5. Il premio è costituito da un oscilloscopio R&S®RTB2000 tra i 10 messi in palio nel periodo dal 1 gennaio 2020 al 31 dicembre 2020:
Premio: 1 oscilloscopio digitale R&S®RTB2000
6. L’estrazione avrà luogo nella sede di Rohde & Schwarz di Muehldorstrasse 15, 81671 Monaco di Baviera. Il vincitore di un premio sarà informato via e-mail entro cinque (5) giorni lavorativi.
7. Il rappresentante autorizzato dalla persona giuridica dovrà informare Rohde & Schwarz della volontà di accettare il premio. In caso di mancata accettazione o di mancata risposta entro due (2) settimane, verrà estratto un nuovo vincitore. Se non si potrà identificare un vincitore entro quattro (4) settimane, il concorso avrà termine e il premio non verrà assegnato.
8. I dipendenti di R&S, i membri delle loro famiglie e le persone coinvolte nel processo di estrazione e i membri delle loro famiglie sono esclusi dalla partecipazione.
9. Non è previsto alcun equivalente in denaro o permuta del premio. I premi non son trasferibili. Tutte le eventuali tasse, imposte, tributi o altri addebiti dovuti nel paese di residenza saranno a carico del partecipante al concorso.
10. I dati personali verranno trattati al solo scopo dell’estrazione del premio e cancellati dopo quattro (4) settimane dall’estrazione, salvo diverso accordo.
11. Ogni partecipante che non rispetta quanto indicato in questi Termini & Condizioni potrà essere squalificato da R&S da questo Concorso. In tali casi, i premi potranno anche essere ritirati retrospettivamente. Qualora un premio venga ritirato retrospettivamente a causa del non rispetto di questi Termini & Condizioni, dovrà essere reso dal vincitore a sue spese, inviandolo all’indirizzo di R&S indicato al punto 1, dopodiché verrà determinato in nuovo vincitore.
12. I partecipanti non potranno richiedere i premi di questo concorso e non è ammesso alcun ricorso legale a questo proposito.
13. Il concorso ed ogni altro legame contrattuale di conseguenza derivante tra R&S e il rispettivo partecipante sarà regolato della legge tedesca, senza possibilità di ricorso in caso di conflitto tra legislazioni. Il tribunale di Monaco di Baviera avrà giurisdizione esclusiva in caso di ogni disputa diretta o indiretta derivante dalla partecipazione a questo Concorso.
* “fast delivery” inside 7 working days applies to the Rohde & Schwarz in-house procedures from order processing through to available ex-factory to ship.
